Model Type

Summit

Dimensions

Length

Overall - 129.9 in. (3,299 mm)Manufacturer spec

Height

Overall - 51.4 in. (1,306 mm)Manufacturer spec

Width

Overall - 42.5 to 43.7 in. (1,080 to 1,110 mm)Manufacturer spec

Engine & Drivetrain

Bore x Stroke

3.2 x 3.2 in. (82 x 80.4 mm)Manufacturer spec

Fuel System

E-TEC® direct injection with additional booster injectorsManufacturer spec

Starting

SHOTManufacturer spec

Drive Clutch

pDrive™ with clickersManufacturer spec

Driven Clutch

QRS Vent PlusManufacturer spec

Drive Sprocket

Pitch - 3.5 in. (89 mm)Manufacturer spec

Clutch Calibration

High AltitudeManufacturer spec

Reverse

RER™Manufacturer spec

Brakes

Brembo racing brake with stainless-steel braided brake lineManufacturer spec

Oil Capacity

3.6 qt. (3.4 l)Manufacturer spec

Operational

Platform/Frame

REV® Gen4 Bodywork - Narrow designManufacturer spec

Handlebar

Tapered U-shaped aluminum with J-hooks / Low grab handle / Flexible handguards Riser block height - 4.7 in. (120 mm)Manufacturer spec

Instrumentation

4.5 in. digital displayManufacturer spec

Skis

Pilot™ DS 3Manufacturer spec

Ski Stance

34 in. (864 mm)Manufacturer spec

Carbide

4 in. Runner - Square 3/8Manufacturer spec

Track Type

PowderMax† Light with FlexEdgeManufacturer spec

Track LxWxH

165 x 16 x 3.0 in.Manufacturer spec

Other

Includes

Heated throttle lever / grips Bumpers (Front / Rear) Belt monitoring systemManufacturer spec

Suspension

Shocks

Front - KYB lightweight high pressure gas Center - HPG™ Plus with lightweight spring Rear - KYB† PRO 36 Easy-AdjustManufacturer spec

Front Suspension

RAS™ 3 with lightweight ski spindle and revised ski stopper Travel - 8.5 in. (215 mm)Manufacturer spec

Rear Suspension

tMotion™ with ice scratchers and adjustable limiter strap Travel - 9.4 in. (239 mm)Manufacturer spec
