Specs
- New or used
- Used
- Availability
- In stock
- Colour
- Dark Royal Red
- Available colours
- Timberline Green Dark Royal RedManufacturer spec
- Torque
- 34.7 lb-ftManufacturer specDealer: Maximum - 34.7 ft. lb. @ 2,500 rpm
- Displacement
- 617 ccManufacturer spec
- Cylinders
- 2Manufacturer spec
- Engine cycle
- Four-strokeManufacturer specDealer: 4-stroke, OHV
- Cooling
- Liquid-cooledManufacturer specDealer: Liquid
- Transmission
- CVTManufacturer spec
- Wheelbase
- 85.2 inManufacturer spec
- Ground clearance
- 7.1 inManufacturer spec
- Wet weight
- 1,586.9 lbManufacturer spec
- Towing capacity
- 1,220 lbManufacturer spec
- Seating
- 2–4Manufacturer spec
- Model code
- KAF620RLF
- Warranty
- Kawasaki Strong 3-Year LimitedManufacturer spec
- VIN
- JK1AFCR14LB537280
- Stock #
- U37280
All details from the dealer (21)
- Model Type
- Mule 4000/4010 2 to 4-Passenger
Brakes/Wheels/Tires
- Brakes
- Front / Rear - Drum Park Brake - Independent, Mechanical DrumManufacturer spec
- Wheels
- SteelManufacturer spec
- Tires
- Front / Rear - 23x11.00-10Manufacturer spec
Dimensions
- Length
- Overall - 128.5 in.Manufacturer spec
- Height
- Overall - 75.8 in.Manufacturer spec
- Width
- Overall - 58.5 in.Manufacturer spec
- Turning Radius
- 12.8 ft.Manufacturer spec
Electrical
- Alternator
- Maximum output - 23 ampManufacturer spec
- Instrumentation
- Parking brake warning light, coolant temperature warning light, horn, 12V DC outlet, fuel gauge, hour meterManufacturer spec
- Lighting
- (2) Halogen headlights, (2) tail/brake lightsManufacturer spec
Engine
- Bore x Stroke
- 2.99 x 2.68 in.Manufacturer spec
- Fuel System
- DFI® with 34 mm Mikuni throttle bodyManufacturer spec
- Fuel Tank Capacity
- 6.3 gal.Manufacturer spec
Operational
- Front Suspension
- MacPherson Strut - 3.9 in. travelManufacturer spec
- Rear Suspension
- DeDion Axle - 2.8 in. travelManufacturer spec
- Steering
- Electric Power Steering (EPS)Manufacturer spec
Other
- Cargo Box Capacity
- 800 lb. (2-person) 400 lb. (4-person)Manufacturer spec
- Cargo Box
- LxWxH - 50.4 x 47.6 x 11.2 in. (2-person) LxWxH - 30.3 x 47.6 x 11.2 in. (4-person)Manufacturer spec
- Load Capacity
- 1,330 lb.Manufacturer spec
- Safety Features
- All MULE side x sides' Rollover Protective Structure (ROPS) meets the performance requirements of ISO 3471Manufacturer spec
From the dealer's page
MULE 4000 TRANS™ and MULE™ 4010 TRANS4x4® side x sides are versatile mid-size two- to four-passenger workhorses that are capable of putting in a hard day of work as well as touring around the property. With the Trans Cab™ system, you get enough room for materials or your entire crew.
