- Frame
- Bridge-type frame, steel shell constructionManufacturer spec
- Front wheel location / suspension
- Upside-down Gabel, diameter 43 mm, spring pre-load manually adjustable, rebound and compression adjustableManufacturer spec
- Rear wheel location / suspension
- Cast aluminum dual swing arm, central WAD spring strut, spring pre-load hydraulically adjustable, rebound damping adjustableManufacturer spec
- Suspension travel, front / rear
- 9.05” / 8.46”Manufacturer spec
- Castor
- 4.72"Manufacturer spec
- Steering head angle
- 62°Manufacturer spec
- Wheels
- Cross spoke wheelsManufacturer spec
- Rim, front
- 2.15 x 21"Manufacturer spec
- Rim, rear
- 4.25 x 17"Manufacturer spec
- Tire, front
- 90/90 R21Manufacturer spec
- Tire, rear
- 150/70 R17Manufacturer spec
- Brake, front
- Twin disc brake, floating brake discs, diameter 305 mm, 2-piston floating caliperManufacturer spec
- Brake, rear
- Single disc brake, diameter 265 mm, 1-piston floating caliperManufacturer spec
- ABS
- BMW Motorrad ABSManufacturer spec
