- Body Style
- GRAY
- Front Shocks
- 2 in FOX shocks with position-sensitive spiral technology and QS3 compression adjusters
- Width
- Bed Box: 17.7 in (45 cm) | Overall: 64 in (162.2 cm)
- Front Brake
- 4-wheel hydraulic disc with triple-bore front and dual-bore rear calipers; aluminum top hat rotor
- Rear Brake
- 4-wheel hydraulic disc with triple-bore front and dual-bore rear calipers; aluminum top hat rotor
- Height
- Bed Box: 11.5 in (29.2 cm) | Overall: 73.6 in (186.9 cm)
- Fuel System
- Electronic fuel injection
- Rear Shocks
- 2.5 in FOX shocks with position-sensitive spiral technology and QS3 compression adjusters
- Suspension (Front)
- High-clearance dual A-arm with stabilizer bar and 20 in (50.8 cm) usable travel, 17 in (43.2 cm) wheel travel*
- Engine Disp to Wgt
- 925 cc
- Drive Train
- System Type: Isolated Xtreme Performance true on-demand AWD/2WD
- Suspension (Rear)
- Trailing arm and standard-clearance radius rods with stabilizer bar and 22 in (55.9 cm) usable travel, 20 in (50.8 cm) wheel travel*
- Length
- Bed Box: 26 in (66 cm) | Overall: 155 in (393.7 cm)
- Max Payload
- 900 lbs. (408.2 kg)
- Wheels
- 14 in cast aluminum rim with 4-lug pattern
- Lighting
- White LED low/high and red LED tail/brake lights.
- Electrical System
- High-output 900-W charging system @ 3,000 RPM
- Cargo System
- Lock & Ride
- Security
- Polaris P.A.S.S. anti-theft system
- Cargo Bed Capacity
- Box: 300 lbs. (136.1 kg)
- Tire Ply Rating
- 8-ply
- Parking Brake
- Park in-transmission
- Door Type
- Half doors
