2026 Polaris Ranger Crew XD 1500 NorthStar Edition Ultimate — photo 1 of 9
1 / 9

Specs

New or used
New
Availability
In stock
Colour
Polaris Pursuit Camo
Available colours
Treeline Green Metallic Super Graphite Smoke Polaris Pursuit CamoManufacturer spec
Horsepower
110 hpManufacturer spec
Displacement
1,498 ccManufacturer spec
Cylinders
3Manufacturer specDealer: Triple
Engine cycle
Four-strokeManufacturer specDealer: 4-Stroke, DOHC
Cooling
Liquid-cooledManufacturer specDealer: Liquid
Fuel
GasManufacturer spec
Transmission
AutomaticManufacturer spec
Drive
Selectable 2WD/4WDManufacturer specDealer: Selectable on-demand all-wheel drive, AWD / 2WD / Turf / Ultra Turf Drive Modes - Comfort, Standard, Sport, Tow / Haul Driveline Features - Drive mode-specific engine braking, hill assist, and creep in drive and reverse
Wheelbase
127 inManufacturer specDealer: 127 in. (322.6 cm)
Ground clearance
15 inManufacturer specDealer: 15 in. (38 cm)
Wet weight
3,380 lbManufacturer specDealer: Curb - 3,380 lb. (1,533 kg) Estimated dry - 3,282 lb. (1,488 kg)
Towing capacity
3,500 lbManufacturer specDealer: 3,500 lb. (1,588 kg) Polaris Pro HD 6,000 lb. Winch with synthetic rope, Auto Stop, wireless remote and Rapid Rope Recovery
Fuel capacity
13.6 galManufacturer specDealer: 13.6 gal. (51.5 l)
Seating
6Manufacturer specDealer: 6 Person Capacity Type - 6-person, dual-row, superior contoured, bolstered bench seats with 3-point harness, heated front row seats, adjustable driver seat, and flip-down arm rest
Model code
R26X6W1RB9
Stock #
N/A
All details from the dealer (24)
Stock Number
N/A
Model Type
Ranger XD 1500 NorthStar Edition

General Information

Stock Number
N/AManufacturer spec

Brakes/Wheels/Tires

Brakes
Front / Rear - Foot-activated and power-assisted, 4-wheel hydraulic disc with dual-bore front and rear calipers Parking - Park In-TransmissionManufacturer spec
Wheels
15 in. AluminumManufacturer spec
Tires
Front - 30 x 10-15; KENDA® CROSS TRAIL Rear - 30 x 11-15; KENDA® CROSS TRAIL Ply Rating - 8-plyManufacturer spec

Dimensions

Length
Overall - 164 in. (416.5 cm)Manufacturer spec
Height
Overall - 78 in. (198 cm)Manufacturer spec
Width
Overall - 65 in. (165 cm)Manufacturer spec
Turning Radius
19.4 ft. (6 m)Manufacturer spec

Electrical

Advanced Electronics
Audio System - JBL Trail Pro 2000 AudioManufacturer spec
Electrical System
140A charging system, Polaris PULSE electrical system (3-position hood and 3-position roof), USB charger, trickle charger Connected Vehicle Services - RIDE COMMAND+Manufacturer spec

Engine

Fuel System
Electronic Fuel InjectionManufacturer spec

Operational

Front Suspension
Dual A-arm Travel - 12 in. (30.5 cm)Manufacturer spec
Rear Suspension
Dual arched A-arm, IRS Travel - 12 in. (30.5 cm)Manufacturer spec
Steering
Tilt & telescoping adjustment Electronic Power Steering - High-output EPSManufacturer spec

Other

Includes
Heat and / or Air Conditioning - Factory-installed heat, AC, defrost, recirculation with 5 different airflow settings Speed limiting controlled in RIDE COMMANDManufacturer spec
Cargo Box Length
43.4 in. (110.2 cm)Manufacturer spec
Cargo Box Height
13.4 in. (34 cm)Manufacturer spec
Cargo Box Width
56 in. (142.2 cm)Manufacturer spec
Cargo Box Capacity
1,500 lb. (680 kg)Manufacturer spec
Cargo Box
System - Electronic lift dump box with Lock & Ride MAX accessory integrationManufacturer spec
Capacity
Payload - 1,650 lb. (748 kg)Manufacturer spec
Hitch
Standard 2 in. (5 cm) ReceiverManufacturer spec

From the dealer's page

We built out this rig for the avid sportsman, outdoorsman, and hunter with gear storage in mind. This 2026 Ranger XD 1500 Crew Northstar Ultimate comes equipped with: • Pro Armor 15" Vegas Wheels w/ 32x10R15 Crawler AT Tires • Polaris Upper Front Bumper • Polaris Front Hood Cargo Storage Rack • Polaris Rear Headache Rack • Polaris Lock & Ride Max Modular Cargo System (MCS) • Polaris Lock & Ride Max MCS Tool Rack • Polaris Lock & Ride Max Rear Rails for MCS • Polaris MCS Tool Rack Extensions • Polaris Rhino-Rack Multi-Purpose Tool Holder • Polaris Contractor Rack Winch Bracket • Polaris Lock & Ride Max D-Rings • Kolpin Ratcheting Rhino Grip • Polaris Door-Mounted Side Mirrors Duck decoys and props are for demonstration purposes and are not included with the machine. Call for pricing or to have one built like this!
