Specs
- New or used
- Used
- Availability
- In stock
- Colour
- White
- Horsepower
- 67 hpManufacturer specDealer: 67 hp (50 kW)
- Displacement
- 690 ccManufacturer specDealer: 42.11 ci (690 cc)
- Cylinders
- 1Manufacturer specDealer: 1-cylinder, 4-stroke
- Engine cycle
- Four-strokeManufacturer specDealer: 1-cylinder, 4-stroke
- Cooling
- Liquid-cooledManufacturer specDealer: Liquid
- Transmission
- ManualManufacturer specDealer: 6-speed, claw-shifted
- Final drive
- 16:40Manufacturer spec
- Mileage
- 11,344 mi
- Seat height
- 32.9 inManufacturer specDealer: 32.87 in. (835 mm)
- Wheelbase
- 57.7 inManufacturer specDealer: 57.72 in. ± 0.59 in. (1,466 ± 15 mm)
- Ground clearance
- 7.6 inManufacturer specDealer: 7.56 in. (192 mm)
- Dry weight
- 329.6 lbManufacturer specDealer: 329.6 lbs. (149.5 kg)
- Model code
- 690DUKE
- VIN
- VBKLDT401DM757404
- Stock #
- KTM57404
All details from the dealer (11)
- Model Type
- Naked Bike
Brakes/Wheels/Tires
- Brakes
- Front: Disc with radially mounted 4-piston caliper; floating disc; 12.6 in. (320 mm) diameterRear: Disc with single-piston caliper, floating; 9.45 in. (240 mm) diameterManufacturer spec
Drivetrain
- Primary Drive
- 36:79Manufacturer spec
Engine
- Bore x Stroke
- 4.02 x 3.33 in. (102 x 84.5 mm)Manufacturer spec
- Clutch
- APTC™ anti-hopping / hydraulically operatedManufacturer spec
- Ignition
- Contactless, controlled fully electronic system with digital timing adjustmentManufacturer spec
- Starting
- E-start, automatic decompressorManufacturer spec
- Lubrication
- Semi-dry sump with 2 rotor pumpsManufacturer spec
Operational
- Frame
- Tubular space made from chrome molybdenum steel, powder-coatedManufacturer spec
- Suspension
- Fork: WP suspension Up Side Down; 5.32 in. (135 mm) travelShock Absorber: WP suspension with Pro-Lever linkage; 5.32 in. (135 mm) travelManufacturer spec
- Rake
- 63.5° steering head angleManufacturer spec
From the dealer's page
Back then, KTM revived the pure, unadulterated single-cylinder motorcycle in the form of the "original" Duke. Judging by the latest 690 Duke that stands before us today, much has been gained: smoothness, room for a pillion passenger, long-distance ability. But what it has never lost is its intensive and elemental ride dynamics. The most cutting-edge series production single-cylinder of our times and a precision chassis with a wealth of outstanding components turn every trip on the 690 Duke into an incomparable and unforgettable riding experience.
Price history
Tracked since Oct 3, 2026 · last checked 2h ago
Price details as printed by the dealer
- Price$3,499
Throttle does not add these up.
Timeline
First seen
Oct 3, 2026
Market context
Comp set: 2011–2015 KTM 690 Duke · 1 listing
Fewer than three comparable units are indexed, so there is no honest median to compare against yet. We would rather show nothing than a number we cannot stand behind.
