Specs
- New or used
- Used
- Availability
- In stock
- Colour
- Olive
- Available colours
- Red, Honda Phantom Camo®Manufacturer spec
- Displacement
- 675 ccManufacturer spec
- Cylinders
- 1Manufacturer specDealer: 675cc liquid-cooled OHV semi-dry-sump longitudinally mounted single-cylinder four-stroke
- Engine cycle
- Four-strokeManufacturer spec
- Cooling
- Liquid-cooledManufacturer spec
- Transmission
- AutomaticManufacturer spec
- Drive
- 4WDManufacturer specDealer: 4x4
- Mileage
- 5,370 mi
- Seat height
- 36.1 inManufacturer spec
- Wheelbase
- 50.8 inManufacturer spec
- Ground clearance
- 9.2 inManufacturer spec
- Wet weight
- 657 lbManufacturer spec
- Fuel capacity
- 4.4 galManufacturer specDealer: 4.4 gallons, including 1.2-gallon reserve
- Model code
- TRX680FAG
- Stock #
- 100932
All details from the dealer (16)
- Model Type
- Rec/Utility
Standard Features
- EMISSIONS
- Meets current California Air Resources Board (CARB) off-road emissions standardsManufacturer spec
Brakes/Wheels/Tires
- Brakes
- Front - Dual hydraulic 180mm disc Rear - Single hydraulic discManufacturer spec
- Tires
- Front - 25 x 8-12 radial Rear - 25 x 10-12 radialManufacturer spec
Dimensions
- Length
- 83.2 inchesManufacturer spec
- Height
- 47.5 inchesManufacturer spec
- Width
- 46.8 inchesManufacturer spec
- Turning Radius
- 10.8 feetManufacturer spec
Drivetrain
- Drive
- Direct front and rear driveshafts with TraxLok® and torque-sensitive front differentialManufacturer spec
Engine
- Bore x Stroke
- 102mm x 82.6mmManufacturer spec
- Compression Ratio
- 9.5:1Manufacturer spec
- Clutch
- AutomaticManufacturer spec
- Fuel System
- Electronic fuel injection (PGM-FI), 40mm throttle bodiesManufacturer spec
- Ignition
- Full-transistorized type with electronic advanceManufacturer spec
- Starting
- Electric with auxiliary recoilManufacturer spec
Operational
- Suspension
- Front - Independent double-wishbone; 7.28 inches travel Rear - Swingarm with single shock; 7.28 inches travelManufacturer spec
From the dealer's page
Some people immediately choose the best in whatever they’re after. And if you’re looking for the best, you’ve come to the right place. The Rincon stands at the top of our ATV lineup. The Rincon offers our biggest ATV engine, unmatched comfort and ride quality, and class-leading innovation. The heart of the matter: a single-cylinder liquid-cooled 675cc engine featuring a twin-plug cylinder head. The longitudinal-crankshaft layout (a Honda innovation) means more power actually gets to the ground, so the Rincon can offer the real-world power of the competition’s bigger, heavier models. Premium long-travel suspension, rugged bodywork, strong steel racks front and rear—the Rincon’s list of features is endless. One thing you can’t see but is readily apparent is the Rincon’s all-day comfort, something serious ATV riders will appreciate. And then there’s just the way the Rincon looks: Strong. Purposeful. Like a flagship ATV should. And to top it all off, you can choose from a wide spectrum of colors for 2016, including Honda Phantom Camo® as well as Red and Olive. Important Safety Information: Recommended for riders 16 years of age and older. Honda recommends that all ATV riders take a training course and read their owner’s manual thoroughly.
Price history
Tracked since Oct 12, 2026 · last checked 4h ago
Price details as printed by the dealer
- Price$5,999
Throttle does not add these up.
LIMITED DATA: one listed price so far (Oct 12, 2026)
- Hawkeye Motorworks (this listing)
Prices as listed by dealers; auction results labelled; a dashed gap = no listed price.
Timeline
First seen
Oct 12, 2026
Market context
Comp set: 2014–2018 Honda FourTrax Rincon · 3 listings
- Median asking
- $5,999
- across 3 comparable listings
- This one
- $5,999
- 0.0% vs median
- Days on market
- New to Throttle
- none have left dealer sites yet
- Left dealer sites
- —
- none yet
