Specs
- New or used
- New
- Availability
- In stock
- Colour
- Brilliant Red
- Available colours
- Billiard Gray Vivid Black Brilliant RedManufacturer spec
- Horsepower
- 149 hpManufacturer specDealer: 149 hp (111 kW) @ 8,750 rpm
- Torque
- 91 lb-ftManufacturer specDealer: 91 ft. lb. (124 Nm)5 @ 6,750 rpm Testing method - J1349 Rider Safety Enhancements - Drag-torque Slip Control System (DSCS), Cornering Drag-Torque Slip Control System (C-DSCS)
- Displacement
- 1,252 ccManufacturer specDealer: 1,252 cc (76.4 ci)
- Cooling
- Liquid-cooledManufacturer specDealer: Coolant Capacity - 2.32 qt. (2.2 l)
- Transmission
- ManualManufacturer specDealer: 6-Speed
- Final drive
- ChainManufacturer spec
- Wheelbase
- 61.8 inManufacturer specDealer: 61.8 in. (1,570 mm)
- Ground clearance
- 6.7 inManufacturer specDealer: Static - 6.7 in. (170 mm) Lean Angle Testing Method - J1168 Right / Left Lean Angle - 37°
- Fuel capacity
- 5.6 galManufacturer specDealer: 5.6 gal. (21.2 l) Reserve, Fuel Injection (warning light) - 1 gal. (3.8 l)
- Battery
- 12 kWhManufacturer specDealer: Sealed, maintenance-free, absorbed glass mat (AGM) battery, 12V, 17.5Ah, 310 CCA at 0°F Charging - Three-phase, 45A system (390W @13V, 1,300 rpm, 585W max power @ 13V, 2,500 rpm)
- Model code
- RA1250ST
- Warranty
- 24 months (unlimited mileage) Service Interval - First 1,000 mi. (1,600 km), every 5,000 mi. (8,000 km) thereafterManufacturer spec
- VIN
- MLY1ZJS14SS305561
- Stock #
- HAR305561
All details from the dealer (25)
- Model Type
- Adventure Touring
Brakes/Wheels/Tires
- Wheels
- Front / Rear - Aluminum cast, satin black3 Front / Rear Diameter - 17 in. (432 mm) Front Width - 3.5 in. (89 mm) Rear Width - 5.5 in. (140 mm) Rider Safety Enhancements - Wheel Lift MitigationManufacturer spec
- Tires
- Type - Michelin® Scorcher "Sport" Front - 120 / 70ZR17 58W Rear - 180 / 55ZR17 73W Front / Rear Model - Scorcher Sport Rider Safety Enhancements - Tire Pressure Monitoring System (TPMS)Manufacturer spec
Dimensions
- Length
- 88.2 in. (2,240 mm)Manufacturer spec
- Height
- 52.4 in. (1,330 mm)Manufacturer spec
- Width
- 35.3 in. (895 mm)Manufacturer spec
Drivetrain
- Primary Drive
- Gear, 49/89 ratioManufacturer spec
Electrical
- Lighting
- (As per country regulation)2 Headlamp - Daymaker® Adaptive LED Headlamp Tail / Stop - All LED Tail / Stop lamp with signature tail lighting Front Signal Lights - LED Bullet Turn SignalsManufacturer spec
- Electrical System
- Electric Power Outlet - USB C-Type, Output 5V at 2.4AManufacturer spec
Engine
- Bore x Stroke
- 4.134 x 2.846 in. (105 x 72.3 mm)Manufacturer spec
- Compression Ratio
- 13.0:1Manufacturer spec
- Gear Ratio
- Overall 1st - 13.11 2nd - 9.687 3rd - 7.509 4th - 6.057 5th - 5.08 6th - 4.436Manufacturer spec
- Clutch
- Mechanical, 8 plate wet, assist and slip, 1090NManufacturer spec
- Fuel System
- Electronic Sequential Port Fuel Injection (ESPFI)6Manufacturer spec
- Exhaust
- 2-into-1-into-1, catalyst in headerManufacturer spec
- Starting
- 0.9 kW electric with direct drive starter motor engagementManufacturer spec
- Lubrication
- Semi-Dry SumpManufacturer spec
- Oil Capacity
- With filter - 4.75 qt. (4.5 l)Manufacturer spec
- MPG Rating
- Estimated City / Hwy - 46 mpg (5.1 l / 100 km)4Manufacturer spec
Operational
- Frame
- Stressed-member, high strength low alloy steel trellis frame, stamped, cast, and forged junctions, MIG welded, aluminum forged mid-structure Swingarm - One-piece cast aluminumManufacturer spec
- Front Suspension
- Travel - 6.7 in. (170 mm)Manufacturer spec
- Rear Suspension
- Travel - 6.7 in. (170 mm) Shocks - Linkage-mounted monoshock with automatic electronic preload control and manually adjustable compression and rebound dampingManufacturer spec
- Rake
- Steering head - 25°Manufacturer spec
- Trail
- 3.7 in. (95 mm)Manufacturer spec
Other
- Includes
- Security System Cruise Control Rider Safety Enhancements - Vehicle Hold Control (VHC), Enhanced Lift MitigationManufacturer spec
From the dealer's page
Building on the proven performance of the Pan America platform, the 2025 Pan America 1250 ST is reimagined for faster, more comfortable, and capable pavement performance, with lowered suspension, quick-shifting, 17-inch wheels, high-performance tires, and a slimmer, lighter profile.
Price history
Tracked since Oct 4, 2026 · last checked 3h ago
Price details as printed by the dealer
- Price$20,549
Throttle does not add these up.
Timeline
First seen
Oct 4, 2026
Market context
Comp set: 2023–2027 Harley-Davidson Pan America 1250 ST · 1 listing
Fewer than three comparable units are indexed, so there is no honest median to compare against yet. We would rather show nothing than a number we cannot stand behind.
