Specs
- New or used
- Used
- Availability
- In stock
- Colour
- Realtree Edge
- Available colours
- Armor Gray Realtree EdgeManufacturer spec
- Displacement
- 686 ccManufacturer spec
- Engine cycle
- Four-strokeManufacturer specDealer: SOHC 4-stroke
- Cooling
- Liquid-cooledManufacturer specDealer: Liquid
- Transmission
- Ultramatic V-belt with all-wheel engine braking; H, L, N, R, PManufacturer spec
- Drive
- 4WDManufacturer specDealer: 4x4
- Mileage
- 3,810 mi
- Seat height
- 36.1 inManufacturer spec
- Wheelbase
- 49.2 inManufacturer spec
- Ground clearance
- 11.3 inManufacturer spec
- Wet weight
- 701 lbManufacturer spec
- Towing capacity
- 1,322 lbManufacturer spec
- Fuel capacity
- 4.8 galManufacturer spec
- Model code
- YFM70GPHMH
- Warranty
- 6 Month (Limited Factory), 10-Year V-Belt LimitedManufacturer spec
- VIN
- 5Y4AMK33XMA102133
- Stock #
- UYA2133
All details from the dealer (15)
- Badge
- On Sale
- Model Type
- Utility ATV
Top Features
- CLASS-LEADING POWER STEERING
- Reduced fatigue, excellent control and trail feel all come standard with the Grizzly EPS’ best-in-industry speed-sensitive Electric Power Steering (EPS).Manufacturer spec
Brakes/Wheels/Tires
- Brakes
- Front / Rear - Dual hydraulic discManufacturer spec
- Tires
- Front - AT26 x 8-12 Maxxis® MU05Y Rear -AT26 x 10-12 Maxxis® MU06YManufacturer spec
Dimensions
- Length
- 81.5 in.Manufacturer spec
- Height
- 49.3 in.Manufacturer spec
- Width
- 48.4 in.Manufacturer spec
- Turning Radius
- 146 in.Manufacturer spec
Drivetrain
- Drive
- Final - On-Command 3-way locking differential; 2WD, 4WD, locked 4WD; shaftManufacturer spec
Engine
- Bore x Stroke
- 102 x 84 mmManufacturer spec
- Compression Ratio
- 10.0:1Manufacturer spec
- Fuel System
- Yamaha Fuel Injection (YFI), 44 mmManufacturer spec
Operational
- Suspension
- Front - Independent double wishbone; 5-way preload adjustment, 7.6-in travel Rear - Independent double wishbone with anti-sway bar; 5-way preload adjustment, 9.1-in travelManufacturer spec
- Load Capacity
- Front rack - 110 lb. Rear rack - 198 lb.Manufacturer spec
From the dealer's page
With superior capability, all-day comfort and legendary durability, the Grizzly EPS is the best-performing ATV in its class.
Price history
Tracked since Oct 2, 2026 · last checked 4h ago
Price details as printed by the dealer
- On Sale$7,250
Throttle does not add these up.
Timeline
First seen
Oct 2, 2026
Market context
Comp set: 2019–2023 Yamaha Grizzly EPS · 1 listing
Fewer than three comparable units are indexed, so there is no honest median to compare against yet. We would rather show nothing than a number we cannot stand behind.
