Specs
- New or used
- Used
- Availability
- In stock
- Colour
- Two-tone Chopper Blue / Brilliant Silver
- Torque
- 85 lb-ftManufacturer specDealer: 85 ft. lbs. (115 nm) @ 3,000 rpm
- Displacement
- 1,442 ccManufacturer specDealer: 88.0 ci (1,450.0 cc)
- Transmission
- ManualManufacturer specDealer: 5-speed
- Final drive
- BeltManufacturer spec
- Mileage
- 63,000 mi
- Seat height
- 25.4 inManufacturer specDealer: 25.4 in. (645.2 mm)
- Wheelbase
- 64.5 inManufacturer specDealer: 64.5 in. (1,638.3 mm)
- Ground clearance
- 5.1 inManufacturer specDealer: 5.1 in. (129.5 mm)
- Dry weight
- 683 lbManufacturer specDealer: 683 lbs. (310 kg)
- Model code
- FATBOY
- VIN
- 1HD1BXB146Y056724
- Stock #
- H56724
All details from the dealer (25)
- Model Type
- Softail®
Chassis
- Lean Angles (per SAEJ1168)
- 29° / 29°Manufacturer spec
Dimensions
- Seat Height (unladen)
- 27.5 in. (698.5 mm)Manufacturer spec
- Oil Capacity
- 3.5 qts. (3.3 l)Manufacturer spec
- Weight (running order)
- 714 lbs. (324 kg)Manufacturer spec
MODEL FEATURES
- MODEL FEATURES
- Fat FL-style front forks with custom-flared front fenderManufacturer spec
- MODEL FEATURES
- Large headlight with fork nacelleManufacturer spec
- MODEL FEATURES
- Chrome tank console, rear fender supportsManufacturer spec
- MODEL FEATURES
- Custom horseshoe oil tank and shotgun-style exhaustManufacturer spec
- MODEL FEATURES
- Wide handlebar and floorboardsManufacturer spec
- MODEL FEATURES
- Black powder-coated engine with chrome coversManufacturer spec
Powertrain
- Miles Per Gallon (Carb)
- 50 hwy / 42 cityManufacturer spec
- Miles Per Gallon (ESPFI)
- 50 hwy / 44 cityManufacturer spec
- Primary Drive
- ChainManufacturer spec
- Gear Ratio (overall)
- 1st - 10.1102nd - 6.9583rd - 4.9534th - 3.8625th - 3.150Manufacturer spec
Brakes/Wheels/Tires
- Brakes
- Front: Single Rear: SingleManufacturer spec
- Tires
- Front: MT90B16 72HRear: 150/80B16 71HManufacturer spec
Dimensions
- Length
- 94.3 in. (2,395.2 mm)Manufacturer spec
Engine
- Bore x Stroke
- 3.75 x 4.00 in. (95.18 x 101.52 mm)Manufacturer spec
- Compression Ratio
- 8.9:1Manufacturer spec
- Clutch
- Multi-plate with diaphragm spring in oil bathManufacturer spec
- Fuel System
- Carburetor or Electronic Sequential Port Fuel Injection (ESPFI)Manufacturer spec
- Exhaust
- Chrome, over / under shotgun with shorty dualsManufacturer spec
Operational
- Rake
- 32.0°Manufacturer spec
- Trail
- 5.8 in. (147.3 mm)Manufacturer spec
From the dealer's page
In the saddle of a Harley-Davidson® Softail®, no road is ever lonely. Sunlight breaks through treetops to dance on chromed steel. The wind offers its constant stream of praise. And the world unfolds before you with open arms. Maybe it’s because nothing else on the road compares with the timeless hardtail styling ... and nothing else feels like a Twin Cam 88B™ power mill rigid-mounted to the frame. Counterbalancing takes care of all but the good vibrations. You and the motorcycle become one, united by an unbreakable bond. Then you feel the hidden rear suspension smooth out the ride with a full 4" of travel. There’s no denying you’re in the saddle of a rolling masterpiece. This year, the Softail family of custom motorcycles welcomes its latest member. We invite you to turn the page and take a gander at the clean lines of the new Heritage Softail®. Additionally, all new bobtail models get a shot of adrenaline in the hindquarters — a brawny, road-hugging 200mm tire under a new wider fender. More rubber to stick to the pavement. More style to keep the eyes glued. Wrap your eyes around the Fat Boy®, if you think you can. There’s a whole lot to love here. It all starts up front with FL-style fork tubes and huge solo chrome headlight. Generous floorboards are welcoming of any boot size. A robust eighty-eight cubic inches of dual-counterbalanced Twin Cam goodness is available carbureted or in super-smooth EFI. The engine belts out its baritone song through a set of shotgun pipes. And the broad tires on Silver Aluminum Disc wheels take all this beef to the road in a style like no other. If you’re ready for something bigger than life, get in the saddle of a Fat Boy®. Once you do, the grin on your face will no doubt get bigger, too. For a limited time, we are offering one-of-a kind, custom color combinations that are over and above the standard two-tone color options available during the model year. These limited color combinations come with a custom decal that is only available through the Custom Color program. Each color has unique complementing pinstripes.
Price history
Tracked since Oct 14, 2026 · last checked 2h ago
Price details as printed by the dealer
- Price$5,969
Throttle does not add these up.
LIMITED DATA: one listed price so far (Oct 14, 2026)
- Interstate 69 Motorsports (this listing)
Prices as listed by dealers; auction results labelled; a dashed gap = no listed price.
Timeline
First seen
Oct 14, 2026
Market context
Comp set: 2004–2008 Harley-Davidson Fat Boy · 1 listing
Fewer than three comparable units are indexed, so there is no honest median to compare against yet. We would rather show nothing than a number we cannot stand behind.
