Model Type

Multistrada

Model Code

NA

Electronic Riding Aid Systems

RIDE-BY-WIRE SYSTEM

Also known as electronic accelerator, it is a system that electronically manages the opening and closing of the throttle (s).Manufacturer spec

DUCATI CORNERING LIGHT (DCL)

LED lights that turn on in the direction of the road, according to a defined lean angle when the bike is facing a curve, allowing the rider to better see the roadManufacturer spec

Features

SUPERBIKE BRAKING SYSTEM

Derived from the Panigale V4, the braking system adopts red Brembo Stylema calipers that act on a pair of 330 mm discsManufacturer spec

General Information

Model Code

NAManufacturer spec

Brakes/Wheels/Tires

Brakes

2 x Ø 330 mm semi-floating discs, radially mounted Brembo Stylema monobloc 4-piston 2-pad calipers, radial master cylinder, Cornering ABS Ø 265 mm disc, Brembo 2-piston floating caliper, Cornering ABSManufacturer spec

Wheels

Front - Marchesini light alloy forged, 3.5 x 17 in. Rear - Marchesini light alloy forged, 6 x 17 in.Manufacturer spec

Tires

Front - Pirelli Diablo Rosso IV Corsa 120 / 70 ZR17 Rear - Pirelli Diablo Rosso IV Corsa 190 / 55 ZR17Manufacturer spec

Drivetrain

Primary Drive

Straight cut gears; Ratio 1.8:1Manufacturer spec

Sprocket

Front - Z15 Rear - Z43Manufacturer spec

Electrical

Instrumentation

6.5 in. TFT color display with Ducati Connect and full-map navigation systemManufacturer spec

Lighting

Daytime Running Light, Ducati Cornering Light, Ducati Brake Light, Full LED headlightManufacturer spec

Advanced Electronics

Riding Mode, Power Mode, Ducati Traction Control, Ducati Wheelie Control, Vehicle Hold Control, Radar system (Adaptive Cruise Control + Blind Spot Detection) Ducati Quick ShiftManufacturer spec

Engine

Bore x Stroke

3.2 x 2.1 in. (81 x 53.5 mm)Manufacturer spec

Compression Ratio

14:1Manufacturer spec

Gear Ratio

1st - 40/13 2nd - 36/16 3rd - 34/19 4th - 31/21 5th - 29/23 6th - 27/25Manufacturer spec

Clutch

Multiplate dry with slipper action on over-runManufacturer spec

Fuel System

Electronic fuel injection system, Øeq 50 mm equivalent elliptical throttle bodies with Ride-by-Wire systemManufacturer spec

Operational

Frame

Aluminum monocoqueManufacturer spec

Front Suspension

Öhlins Ø 48 mm fully adjustable usd fork with TiN treatment, electronic compression and rebound damping adjustment with Öhlins Smart EC 2.0 event-based mode 6.7 in. (170 mm)Manufacturer spec

Rear Suspension

Öhlins TTX36 fully adjustable monoshock, electronic compression and rebound damping adjustment with Öhlins Smart EC 2.0 event-based mode, electronic preload adjustment, aluminum single-sided swingarm 6.7 in. (170 mm)Manufacturer spec

Rake

25.75°Manufacturer spec

Trail

4.7 in. (120 mm)Manufacturer spec

Seat

2Manufacturer spec

Handlebars

Backlit switchesManufacturer spec

Other

Includes

Hands-free, Carbon fiber front mudguard and beak, Carbon fiber handguards, Type-approved Akrapovic mufflerManufacturer spec
