Model Type

Multistrada

Model Code

NA

Electronic Riding Aid Systems

DUCATI SKYHOOK SUSPENSION (DSS)

Semi-active suspension management system that "reads" the road and modifies the suspension reaction to offer greater comfort while driving and reduce load transfers in the case of decisive braking and acceleration, to the benefit of controlManufacturer spec

RIDE-BY-WIRE SYSTEM

Also known as electronic accelerator, it is a system that electronically manages the opening and closing of the throttle (s).Manufacturer spec

Vehicle

SEAT ADJUSTABLE TO TWO HEIGHTS

Ergonomics are optimized with the possibility to adjust the seat to a standard height of either 33.5 in or 32.7 in .Manufacturer spec

General Information

Model Code

NAManufacturer spec

Brakes/Wheels/Tires

Brakes

Front - 2 x Ø 320 mm semi-floating discs, radially mounted Brembo monobloc 4-piston 2-pad calipers, radial master cylinder, Cornering ABS Rear - Ø 265 mm disc, Brembo 2-piston floating caliper, Cornering ABSManufacturer spec

Wheels

Front - Light alloy cast, 3 x 19 in. Rear - Light alloy cast, 4.5 x 17 in.Manufacturer spec

Tires

Front - Pirelli Scorpion Trail II 120 / 70 ZR 19 Rear - Pirelli Scorpion Trail II 170 / 60 ZR 17Manufacturer spec

Drivetrain

Primary Drive

Straight cut gears; Ratio 1.84:1Manufacturer spec

Sprocket

Front - 15 Rear - 40Manufacturer spec

Electrical

Battery

Lithium-ionManufacturer spec

Instrumentation

Digital unit with 5 in. TFT color Display, 800 x 480 px ResolutionManufacturer spec

Advanced Electronics

Riding Modes, Power Modes, Ducati Traction Control (DTC), Ducati Wheelie Control (DWC) Cruise ControlManufacturer spec

Engine

Bore x Stroke

3.8 x 2.4 in. (96 x 61.5 mm)Manufacturer spec

Compression Ratio

13.1:1Manufacturer spec

Gear Ratio

1st - 38 / 13 2nd - 35 / 17 3rd - 32 / 20 4th - 29 / 22 5th - 24 / 21 6th - 26 / 25Manufacturer spec

Clutch

Hydraulically controlled slipper and self-servo wet multiplateManufacturer spec

Fuel System

Electronic fuel injection system, Ø 52 mm throttle body with Ride-by-wireManufacturer spec

Exhaust

Stainless steel muffler, single catalytic converter and lambda probesManufacturer spec

Operational

Frame

Monocoque AluminumManufacturer spec

Front Suspension

Ø 45 mm fully adjustable mechanical fork, compression and rebound damping manual adjustment Wheel travel - 6.7 in. (170 mm)Manufacturer spec

Rear Suspension

Fully adjustable monoshock, Remote spring preload adjustment, aluminum double-sided swingarm Wheel travel - 6.7 in. (170 mm)Manufacturer spec

Rake

24.3°Manufacturer spec

Trail

4.15 in. (105.5 mm)Manufacturer spec

Seat

2Manufacturer spec

Other

Includes

Auto-off indicators, USB portManufacturer spec
