Status

In-Stock

Lot Status

On Lot

Engine

Rated output

145 hp at 7,750 rpmManufacturer spec

Type

Air/liquid-cooled four-stroke flat twin engine with double overhead and chain driven camshafts (BMW ShiftCam)Manufacturer spec

Bore x stroke

106.5 mm x 73 mmManufacturer spec

Capacity

1,300 ccManufacturer spec

Max. torque

110 lb-ft at 6,500 rpmManufacturer spec

Compression ratio

13.3 : 1Manufacturer spec

Mixture control

Electronic intake pipe injectionManufacturer spec

Performance / fuel consumption

Maximum speed

over 120 mphManufacturer spec

Electrical system

Alternator

Three-phase alternator with 650 W (nominal power)Manufacturer spec

Power transmission

Gearbox

Constant-mesh 6-speed gearbox integrated in the transmission housingManufacturer spec

Traction control

BMW Motorrad DTCManufacturer spec

Chassis / brakes

Frame

Two-part frame consisting of main frame, bolted rear frame, and load-bearing engineManufacturer spec

Front wheel location / suspension

BMW Motorrad EVO-Telelever, handlebar tilting decoupled via flex element, central DSA shock absorberManufacturer spec

Rear wheel location / suspension

BMW Motorrad EVO-Paralever, cast aluminum single-sided swingarm, transversal connected swing arm bearings, central DSA spring strut, load compensationManufacturer spec

Suspension travel, front / rear

8.3" / 8.7"Manufacturer spec

Castor

4.67"Manufacturer spec

Steering head angle

63.8 °Manufacturer spec

Wheels

Cross spoke wheelsManufacturer spec

Rim, front

3.00 x 19“Manufacturer spec

Rim, rear

4.50 x 17“Manufacturer spec

Tire, front

120/70 R19Manufacturer spec

Tire, rear

170/60 R17Manufacturer spec

Brake, front

Twin disc brake, semi-floating brake discs, diameter 310 mm, 4-piston radial brake caliperManufacturer spec

Brake, rear

Single disc brake, bolted to the disc rim, diameter 285 mm, 2-piston floating caliperManufacturer spec

ABS

BMW Motorrad Full Integral ABS Pro (lean angle optimized)Manufacturer spec

Dimensions / weights

Seat height at unladen weight

34.25" / 35.0"Manufacturer spec

Inner leg curve at unladen weight

72.4" / 77.9"Manufacturer spec

Usable tank volume

7.9 galManufacturer spec

Reserve

approx. 1 galManufacturer spec

Length

89.76" (over splash guard)Manufacturer spec

Height

62.5" (above windshield, at unladen weight)Manufacturer spec

Width

39.8" (over hand guard)Manufacturer spec

Permitted total weight

1,069 lbsManufacturer spec

Payload (with standard equipment)

478 lbsManufacturer spec

Unladen weight, road ready, fully fueled

593 lbs 1)Manufacturer spec

Vehicle record

Body Style

Motorcycle
