Status

In-Stock

Lot Status

On Lot

Engine

Rated output

105 hp at 8,500 rpmManufacturer spec

Emission control

Closed-loop 3-way catalytic converterManufacturer spec

Type

Water-cooled, 2-cylinder, four-stroke engine with four cam-operated valves per cylinder, two overhead camshafts and dry-sump lubricationManufacturer spec

Bore x stroke

86 mm x 77 mmManufacturer spec

Capacity

895 ccManufacturer spec

Compression ratio

13.1 : 1Manufacturer spec

Mixture control

Electronic intake pipe injection / digital engine management system: BMS-X with throttle-by-wireManufacturer spec

Max. torque

68.6 lb-ft at 6,750 rpmManufacturer spec

Performance / fuel consumption

Maximum speed

over 120 mphManufacturer spec

Electrical system

Alternator

Permanent magnet alternator with 416 W (nominal power)Manufacturer spec

Power transmission

Clutch

Multiplate clutch in oil bath, slipper clutchManufacturer spec

Chassis / brakes

Frame

Bridge-type frame, steel shell constructionManufacturer spec

Steering head angle

62°Manufacturer spec

Wheels

Cross spoke wheelsManufacturer spec

Rim, front

2.15 x 21"Manufacturer spec

Rim, rear

4.25 x 17"Manufacturer spec

Tire, front

90/90 R21Manufacturer spec

Tire, rear

150/70 R17Manufacturer spec

Brake, front

Twin disc brake, floating brake discs, diameter 305 mm, 2-piston floating caliperManufacturer spec

Brake, rear

Single disc brake, diameter 265 mm, 1-piston floating caliperManufacturer spec

ABS

BMW Motorrad ABSManufacturer spec

Castor

4.71"Manufacturer spec

Suspension travel, front / rear

9.05” / 8.46”Manufacturer spec

Front wheel location / suspension

Upside-down Gabel, diameter 43 mm, spring pre-load manually adjustable, rebound and compression adjustableManufacturer spec

Dimensions / weights

Seat height at unladen weight

34.2" (OE lowering: 32.0"; OE rally seat high: 35.0"; OE rally seat low: 32.8"; OA single seat: 34.2")Manufacturer spec

Reserve

approx. 1 galManufacturer spec

Unladen weight, road ready, fully fueled

482 lbs 1)Manufacturer spec

Permitted total weight

981 lbsManufacturer spec

Payload (with standard equipment)

498 lbsManufacturer spec

Width

37.1" (without accessories)Manufacturer spec

Height

54.8” (above windshield)Manufacturer spec

Length

89.4" (over mud guard)Manufacturer spec

Usable tank volume

3.8 galManufacturer spec

Inner leg curve at unladen weight

76.1" (OE lowering: 70.8"; OE rally seat high: 77.3"; OE rally seat low: 74.8"; OA single seat: 76.1")Manufacturer spec

Vehicle record

Body Style

Motorcycle
