Specs
- New or used
- Used
- Availability
- In stock
- Colour
- Realtree Xtra Green Camo
- Torque
- 42.7 lb-ftManufacturer specDealer: Maximum - 42.7 ft. lb. @ 4,750 rpm
- Displacement
- 749 ccManufacturer spec
- Cylinders
- 2Manufacturer specDealer: 4-stroke, V-twin, SOHC
- Engine cycle
- Four-strokeManufacturer specDealer: 4-stroke, V-twin, SOHC
- Cooling
- Liquid-cooledManufacturer specDealer: Liquid
- Transmission
- CVTManufacturer spec
- Drive
- 4WDManufacturer specDealer: 4x4
- Seat height
- 35.8 inManufacturer spec
- Wheelbase
- 50.6 inManufacturer spec
- Ground clearance
- 9.4 inManufacturer spec
- Wet weight
- 699 lbManufacturer spec
- Towing capacity
- 1,250 lbManufacturer spec
- Fuel capacity
- 5 galManufacturer spec
- Model code
- KVF750HNFNN
- Warranty
- 12 Month LimitedManufacturer spec
- VIN
- JKAVFDH17NB509355
- Stock #
- NB509355-U
All details from the dealer (21)
- Model Type
- Utility / Recreation
Mammoth Power
- A CONQUEROR ON FOUR WHEELS
- Generous 1,250-pound towing capacity is complemented by sturdy cargo racks that hold up to 264 pounds (88 pounds in front and 176 pounds in rear).Manufacturer spec
Brakes/Wheels/Tires
- Brakes
- Front - Dual hydraulic 176 mm discs with 2-piston calipers Rear - Sealed, oil-bathed, multi-disc with independent park brakeManufacturer spec
- Wheels
- Front track - 36.4 in. Rear track - 35 in.Manufacturer spec
- Tires
- Front - AT 25 x 8-12 Rear - AT 25 x 10-12Manufacturer spec
Dimensions
- Length
- Overall - 86.4 in.Manufacturer spec
- Height
- Overall - 48 in.Manufacturer spec
- Width
- Overall - 46.5 in.Manufacturer spec
- Turning Radius
- 10.5 ft.Manufacturer spec
Drivetrain
- Drive
- Final - Selectable 2WD / 4WD with variable control front differential lock, shaftManufacturer spec
Electrical
- Instrumentation
- Speedometer, odometer, dual trip meters, fuel gauge, engine temp, clock, hour meter and 2WD / 4WD icon, plus indicators for EPS, neutral, belt, and oil pressureManufacturer spec
- Lighting
- 35W headlights, 5W taillight, 21W stoplightManufacturer spec
Engine
- Bore x Stroke
- 85 x 66 mmManufacturer spec
- Compression Ratio
- 9.3:1Manufacturer spec
- Fuel System
- DFI® with two 36 mm throttle bodiesManufacturer spec
- Ignition
- Digital DC-CDIManufacturer spec
- Starting
- ElectricManufacturer spec
Operational
- Frame
- Double-cradle, high-tensile tubular steelManufacturer spec
- Suspension
- Front / Rear - Double wishbone Front travel - 6.7 in. Rear travel - 7.5 in.Manufacturer spec
- Steering
- Electronic Power Steering (EPS)Manufacturer spec
- Load Capacity
- Front rack - 88 lb. Rear rack - 176 lb. Total Rack Capacity - 242 lb.Manufacturer spec
From the dealer's page
Powered by a fuel-injected 749cc V-twin engine that delivers mammoth power, the Brute Force® 750 4x4i ATV offers high-level performance for your outdoor adventures. With 1,250-lb towing capacity and independent suspension, this ATV is suitable for people ages 16 and older.
Price history
Tracked since Oct 13, 2026 · last checked 2h ago
Price details as printed by the dealer
- Price$4,788
Throttle does not add these up.
LIMITED DATA: one listed price so far (Oct 13, 2026)
- BIG HOMETOWN MOTORSPORTS (this listing)
Prices as listed by dealers; auction results labelled; a dashed gap = no listed price.
Timeline
First seen
Oct 13, 2026
Market context
Comp set: 2020–2024 Kawasaki Brute Force 750 4x4i EPS Camo · 1 listing
Fewer than three comparable units are indexed, so there is no honest median to compare against yet. We would rather show nothing than a number we cannot stand behind.
