Engine

Rated output

170 hp at 11,000 rpmManufacturer spec

Type

Oil/water-cooled, four-cylinder, four-stroke, in-line engine with four valves per cylinderManufacturer spec

Bore x stroke

80 mm x 49.7 mmManufacturer spec

Capacity

999 ccManufacturer spec

Max. torque

84 lb-ft at 9,250 rpmManufacturer spec

Compression ratio

12.5 : 1Manufacturer spec

Mixture control

Electronic intake pipe injection / digital engine management system: BMS-O with throttle-by-wireManufacturer spec

Max. RPM

12,000 rpmManufacturer spec

Performance / fuel consumption

Maximum speed

over 155 mphManufacturer spec

Electrical system

Alternator

Permanent magnet alternator with 493 W (nominal power)Manufacturer spec

Power transmission

Clutch

Multiplate clutch in oil bath, slipper clutch, self-reinforcingManufacturer spec

Gearbox

Constant-mesh 6-speed gearbox integrated in the transmission housingManufacturer spec

Traction control

BMW Motorrad DTCManufacturer spec

Chassis / brakes

Frame

Bridge-type frame, cast aluminum, load-bearing engineManufacturer spec

Front wheel location / suspension

Upside-down telescopic fork, diameter 45 mm, electronic self-adjusting rebound/compression damping (Dynamic ESA)Manufacturer spec

Rear wheel location / suspension

Aluminum double-sided swing arm, central shock absorber, electronic preload adjuster, electronic self-adjusting rebound/compression damping (Dynamic ESA)Manufacturer spec

Suspension travel, front / rear

5.9" / 5.9"Manufacturer spec

Castor

4.64"Manufacturer spec

Steering head angle

64.8°Manufacturer spec

Wheels

Aluminum cast wheelsManufacturer spec

Rim, front

3.50 x 17"Manufacturer spec

Rim, rear

6.00 x 17"Manufacturer spec

Tire, front

120/70 ZR17Manufacturer spec

Tire, rear

190/55 ZR17Manufacturer spec

Brake, front

Twin disc brake, diameter 320 mm, 4-piston fixed caliperManufacturer spec

Brake, rear

Single disc brake, diameter 265 mm, 2-piston floating caliperManufacturer spec

ABS

BMW Motorrad Integral ABS (partial integral)Manufacturer spec

Dimensions / weights

Seat height at unladen weight

33.5" (OE lowering: 31.1")Manufacturer spec

Inner leg curve at unladen weight

75" (OE lowering: 71.2")Manufacturer spec

Usable tank volume

5.2 galManufacturer spec

Reserve

approx. 1 galManufacturer spec

Length

84.8" (over rear wheel)Manufacturer spec

Height

57.5" (without mirror)Manufacturer spec

Width

33.5" (without accessories)Manufacturer spec

Unladen weight, road ready, fully fueled

500 lbs 1)Manufacturer spec

Permitted total weight

992 lbsManufacturer spec

Payload (with standard equipment)

491.6 lbsManufacturer spec

Vehicle record

Body Style

Motorcycle
