Specs
- New or used
- Used
- Availability
- In stock
- Colour
- Redline Red
- Horsepower
- 94 hpManufacturer specDealer: 94 hp (70 kW) @ 4,750 rpm
- Torque
- 119 lb-ftManufacturer specDealer: 119 ft. lb. (161 Nm)2@ 3,000 rpm Engine Testing Method - J1349
- Displacement
- 1,868 ccManufacturer specDealer: 1,868 cc (114 ci)
- Transmission
- ManualManufacturer specDealer: Capacity - 1 qt. (0.95 l) 6-Speed Cruise Drive®
- Mileage
- 17 mi
- Seat height
- 26.1 inManufacturer specDealer: Laden - 26.1 in. (663 mm)7 Unladen - 27 in. (687 mm)
- Wheelbase
- 64.2 inManufacturer specDealer: 64.2 in. (1,630 mm)
- Ground clearance
- 27.4 inManufacturer spec
- Dry weight
- 711 lbManufacturer specDealer: As Shipped - 711 lb. (322 kg) In Running Order - 742 lb. (336 kg) Gross Vehicle Rating - 1,160 lb. (526 kg)
- Fuel capacity
- 5 galManufacturer specDealer: 5 gal. (18.9 l)
- Model code
- FLI
- VIN
- 1HD1BCK11RB031280
- Stock #
- RB031280
All details from the dealer (22)
- Model Type
- Icons
Brakes/Wheels/Tires
- Brakes
- Front Caliper Type - 4-piston fixed Rear Caliper Type - 2-piston floating Rotor Type - Solid, uniform expansion rotors Rider Safety Enhancements - Anti-lock Brake System (ABS)Manufacturer spec
- Wheels
- Front / Rear Type - Chrome Steel Laced9Manufacturer spec
- Tires
- Front / Rear Type - Dunlop® Harley-Davidson Series, bias blackwall Front - 130 / 90B16, 73H, BW Rear - 150 / 80B16, 77H, BWManufacturer spec
Dimensions
- Length
- 95.1 in. (2,415 mm)Manufacturer spec
- Height
- Overall - 57.8 in. (1,468 mm)Manufacturer spec
- Width
- Overall - 36.6 in. (930 mm)Manufacturer spec
Drivetrain
- Primary Drive
- Chain, 34 / 46 ratioManufacturer spec
- Chain
- Primary Case Capacity - 1.25 qt. (1.18 l)Manufacturer spec
Electrical
- Instrumentation
- Gauges - 5 in. analog speedometer with digital gear, odometer, fuel level, clock, trip, range and tachometer indicationManufacturer spec
Engine
- Bore x Stroke
- 4.016 x 4.5 in. (102 x 114.3 mm)Manufacturer spec
- Compression Ratio
- 10.5:1Manufacturer spec
- Gear Ratio
- Overall 1st - 9.311 2nd - 6.454 3rd - 4.793 4th - 3.882 5th - 3.307 6th - 2.79Manufacturer spec
- Fuel System
- Electronic Sequential Port Fuel Injection (ESPFI)3Manufacturer spec
- Exhaust
- 2-into-2 shorty dual, catalyst in mufflerManufacturer spec
- Oil Capacity
- With filter - 5 qt. (4.7 l)Manufacturer spec
- MPG Rating
- Estimated City / Hwy - 47 mpg (5 l / 100 km)5Manufacturer spec
Operational
- Rear Suspension
- Shocks - Hidden, free piston, coil-over monoshock, 43 mm stroke, cam-style preload adjustmentManufacturer spec
- Rake
- 30°Manufacturer spec
- Trail
- 5.7 in. (145 mm)Manufacturer spec
- Fork
- Angle - 30° Front - Dual-bending valve 49 mm telescopic with aluminum fork triple clamps; dual rate spring; "beer can" coversManufacturer spec
Other
- Cargo Capacity
- Luggage Volume - 1.5 cu. ft. (0.043 cu. m)Manufacturer spec
From the dealer's page
To celebrate the 75th anniversary of the Hydra-Glide, a champion of the Panhead era is resurrected with the release of the limited-edition 2024 Hydra-Glide Revival.
Price history
Tracked since Oct 3, 2026 · last checked 2h ago
Price details as printed by the dealer
- Price$24,999
- DOC Fee+ $160
Throttle does not add these up.
Timeline
First seen
Oct 3, 2026
Market context
Comp set: 2022–2026 Harley-Davidson Hydra-Glide Revival · 2 listings
Fewer than three comparable units are indexed, so there is no honest median to compare against yet. We would rather show nothing than a number we cannot stand behind.
